Group: 23 Fuel system
Repair instructions
Pressure limiting valve, change Cover removed 1.
Carefully clean the area on the engine around the pressure limiting valve.
IMPORTANT! Be very careful with cleanliness during the entire job. Be careful to ensure that no dirt particles get into the fuel system. 2.
Unscrew the pressure limiting valve (1) and remove it.
3.
Check that the contact surfaces on the pressure limiting valve are not scratched.
4.
Install the pressure limiting valve and torque it to 85 Nm.
5.
Wipe up the fuel that has run out.
1
Start the engine and check for leakage.
143
