Repair instructions
Group: 21 Short block
Cylinder head, change Current cut. Drained cooling system and sea water. Removal 1. Remove the cover and the fuel filter bracket. 2.
Undo the sea water hoses and all the intercooler hose connections to inlet and turbo pipes.
3.
Remove the electric connector (1) on the intercooler, together with the dipstick bracket (2).
4.
Remove the intercooler, 4 screws, and the mounting bracket.
1
Remove the reverse gearbox oil cooler.
2
5.
Undo the cables on the starter motor. Unscrew the starter motor (1), note the guide pin (2).
110
