Introduction to Maserati
Quattroporte
Central door locking system Locking/unlocking the vehicle using the key: Key rotated anticlockwise in lock on DRIVER’s door (opening). All 4 doors are unlocked (or driver’s door only if set with NIT); if the alarm is connected: the red leds turn off for 4 seconds (after which they will start flashing again) Key rotated clockwise in lock on passenger’s door: All 4 doors are unlocked; if the alarm is connected: the red leds turn off for 4 seconds (after which they will start flashing again) N.B: When the vehicle is unlocked from the outside with the key, the alarm is not disarmed. To disarm the alarm, simply insert the key in the ignition lock. The immobilizer acknowledges the code automatically. Luggage compartment opening button: Long press: luggage compartment opens (when vehicle speed is below 4 km/h or when the ignition switch is set to off Inertial switch: The intervention of the inertial switch results in the release of all the doors and the luggage compartment, and the internal ceiling light and the four direction indicators switching on. It is located beneath the front seat on the driver’s side. Vehicle speed over 20 Km/h: When the vehicle speed exceeds 20 Km/h the doors are locked if this function has been previously set in the IT Info Node (NIT) user menu Luggage compartment closing: To close the luggage compartment, simply rest it on the lock. Vehicle closing with flat or disconnected battery: The 2 front doors must be closed with the key and the 2 rear doors with the small lever hidden beneath the weather strip, near the lock. Vehicle setup: From the NIT user menu, the driver can decide whether tounlock all the doors or just the door on the driver’s side. Using the relevant menu, the driver can select whether the opening/closing of the luggage compartment should be linked to the central door locking or it should be independent.
Maserati Academy
140
