Chapter 5
Jumper and Connector Locations Top View
Item
Description
Item
Description
JLVDS1
LCD Connector
JP7
FP/B Connector
JP23
MIC-In Jack
JP10
Bluetooth Connector
JP16
BTN/B Connector
JMDC1
MDC Connector
JP17
Fun/B Connector
SW5
Touch pad (right) Button
JP19
Speaker (Left) Connector
SW1
Touch pad (left) Button
JP20
Speaker (Right) Connector
JPCM1
PCMCIA Connector
JP15
Internal Keyboard Connector
U10
South Bridge
JP13
Touch Pad Connector
