Functions of and How to Use Adjustment Mode Functions of and How to Use Adjustment Mode Adjustment Procedures WARNING Before making an adjustment, extend the outriggers fully and set the crane on firm ground for safety. [NOTICE] You can adjust the boom length and boom angle in random order. After whole adjustment is completed, erase-protect the overload history, referring to "Erasing the Overload History" in the "Functions of How to Use Adjustment Mode" section. The adjustment items and procedures are as follows: 1. Adjustment Initialization 2. Boom Length Adjustment 3. Boom Angle Adjustment 4. Swing Angle Adjustment (*1) 5. Outrigger Extension Width Adjustment (*2) 6. Jib Angle Adjustment (*2) 7. Jib Length Adjustment (*2) 8. Moment Adjustment (including load radius adjustment) 9. Clock Adjustment Adjustment Completed Erasing the Overload History (*1) (*2)
: Not apply to TS-75M-1. : Not apply to TS-75M-1, GT-250C-1 and GT-350C-1.
70
W301-0251E
