Functions of and How to Use User Mode (GT-250C-1/GT-350C-1) Lifting Height Limit
Load Radius Limit
Move the boom to a desired limit height, and
Move the boom to a desired limit load radius, and
press the lifting height limit key. The lifting height limit indicator lamp will flash and the alarm buzzer will sound continuously, indicating that the height limit has been registered in the memory. When the boom is moved back to a height within the set limit, the lifting height limit indicator lamp stops flashing and stays lit, and the alarm buzzer stops. Thereafter, the lifting height limit indicator lamp flashes and the alarm buzzer sounds continuously whenever the height limit previously registered is reached. (Boom raising and extending stop automatically.) To cancel the height limit, press the lifting height limit key again. The lifting height limit indicator lamp will go out.
press the load radius limit key. The load radius limit indicator lamp will flash and the alarm buzzer will sound continuously, indicating that the load radius limit has been registered in the memory. When the boom is moved back to a load radius within the set limit, the load radius limit indicator lamp stops flashing and stays lit, and the alarm buzzer stops. Thereafter, the load radius limit indicator lamp flashes and the alarm buzzer sounds continuously whenever the load radius previously registered is reached. (Boom lowering and extending stop automatically.) To cancel the load radius limit, press the load radius limit key again. The load radius limit indicator lamp will go out.
Lifting height limit indicator lamp Load radius limit indicator lamp
Lifting height limit key
Load radius limit key
60
W301-0251E
