Page 54

Functions of and How to Use User Mode (GT-250C-1/GT-350C-1) Registering Operating Conditions

To register the outrigger condition, use the outrigger condition selector key and set key.

WARNING Should the operational status be incorrectly registered, the crane may overturn or be damaged, leading to a serious accident. Prior to every operation, check that the registered status corresponds to the actual status of the crane.

Registration of Outrigger Condition [NOTICE] Register right and left outrigger condition separately on the AML. If the front and rear outrigger extension widths differ, register the smaller extension width as shown in the figure below. Left front/rear middle extension

Left front middle extension

Set key

Left rear middle extension

Right outrigger condition selector key Left outrigger condition selector key

Either extension status on the left is registered as middle extension.

Each time the outrigger condition selector key is pressed, the outrigger condition symbol flashes with alternate display of [Middle extension] → [Maximum extension] → [Middle extension] → [Maximum extension]. After adjusting the right and left symbol display to the actual outrigger extension, press the set key. The outrigger condition symbol changes from "flashing" to "being lit" to indicate that the condition has been successfully registered.

When the power supply is turned on (the engine begins running and the PTO switch in the cab is turned "ON"), the on-rubber condition symbol lights. Even after the power supply is turned off (PTO switch: OFF), the AML stores the operational status if the power supply is turned on again within approximately 2 hours. However, the maximum storage period is 2 hours. If 2 hours or more have passed after the power supply was turned off (PTO switch: OFF), the registered data is automatically erased. To resume the operation, register the settings all over again.

53

W301-0251E
