Functions of and How to Use User Mode (GT-250C-1/GT-350C-1) registered load radius limit value is displayed while the set key is pressed.
B. Display panel 1
10. Boom angle display Normally displays the boom angle. When the lower limit function of boom angle is activated, the registered limit value is displayed while the set key is pressed. 11, 12. Boom angle symbols This symbol indicates that the boom angle display 10 is showing the boom angle. 13. Single top lift symbol This symbol indicates that the single top performance is selected. 1. Boom length symbol This symbol indicates that the boom length display 20 is showing the boom length.
14. Boom lift symbol
2. Jib length symbol
15, 16. Lower boom angle limit symbols
This symbol indicates that the boom lift is selected.
This symbol indicates that the boom angle display 10 is showing the registered lower boom angle limit value.
Not used in this machine. 3. Jib angle symbol This symbol indicates that the jib angle display 23 is showing the jib offset angle.
17, 18. Upper boom angle limit symbols This symbol indicates that the jib angle display 23 is showing the registered upper boom angle limit value.
4. Jib lift symbol This symbol indicates that the jib lift is selected. It also indicates the condition of the jib.
19. Counterweight condition symbol
5. Actual load display
Not used in this machine.
Displays the actual load.
20. Boom length display
6. Rated lifting capacity display
Normally displays the boom length. Displays the lifting height while the display alteration key is pressed. When the lifting height limit function is activated, the registered limit value is displayed while the set key is pressed.
Displays the rated lifting capacity. 7. Load radius limit symbol This symbol indicates that the load radius display 9 is showing the registered load radius limit value. The load radius symbol 8 is also lit at the same time when this symbol is lit.
21. Lifting height symbol This symbol indicates that the boom length display 20 is showing the lifting height.
8. Load radius symbol This symbol indicates that the load radius display 9 is showing the load radius.
22. Lifting height limit symbol This symbol indicates that the boom length display 20 is showing the registered lifting height limit value. The lifting height symbol 21 is lit at the same time when this symbol is lit.
9. Load radius display Normally displays the crane’s load radius. When the load radius limit function is activated, the
50
W301-0251E
