Functions of and How to Use User Mode (TS-75M-1) [OPERATION]
2. Maintenance Mode: Used to make functional checks of the AML. Refer to the "ADJUSTMENT AND MAINTENANCE" section.
Functions of and How to Use User Mode (TS-75M-1)
3. Adjustment Mode:
Mode Structure
Used to make detector adjustment. Refer to the "ADJUSTMENT AND MAINTENANCE" section.
The AML device has three modes and the AML functions are allotted for these models. POWER ON 電源 ON
Protect プロテクト switch スイッチ
MAINTENANCE MODE 保守モード
USER MODE ユーザーモード
ON ON Protect プロテクト switch スイッチ OFF OFF
調整モード ADJUSTMENT MODE
POWER ON 電源 ON
IW301-0153J03
1. User Mode: Used to indicate moment load factor or to perform AML pre-operational inspection (Normally used). In normal use, turn ON the protect switch mounted on the adjustment window on the top of the AML. The AML will go to the user mode when the power turns ON. The abnormality display LED lights when the AML
HALT
ON
OFF
WDT
PROTECT
is in abnormal conditions (to indicate that the CPU is faulty).
Protect 異常表示LED Abnormality switch display LED プロテクトスイッチ Top上面 view
IW301-0141J35
32
