Control and operation
Operating manual
Operating and control elements
Overload warning device (optional equipment) For a machine fitted with the optional equipment "overload warning device", and if this equipment has been turned on via the switch S18, this symbol alerts the operator that the load limit of the machine has been reached At the same time the buzzer sounds to alert the operator to this fact. No overload warning device recognized This symbol appears if switching on the overload warning device via switch S18 though no overload warning device has been installed and/or correctly initialised on the machine. Warm up procedure This symbol appears during a warm up procedure of the hydraulic oil. Working pumps swivelled back to minimum delivery
3.1.6
Information provided in the menus Menu selection from main screen:
Fig. 3-10
Main screen
To change to the list of menus, the main screen must be visible. With the main screen visible, press the Menu key of the display. The list of accessible menus is displayed.
Fig. 3-11
List of menus
copyright by
3 - 18
MJFCIFSS
ER 954 C - High-Rise / 11211691
