Control and operation
Operating manual
Operating and control elements
S19 – Rotating device (optional equipment) The rotating device is an additional hydraulic circuit necessary to drive some specific equipments (such as rotating grapple, rotating bucket, rotating stick, quick change coupling, ...). Press the touch: LED in the touch illuminates, the control circuit for the rotating device is activated. Now the special equipment (as an ex. the rotating grapple) can be actuated using the push buttons S5L and S5R in the handle of the left joystick unit. Press the touch again: LED in the touch goes out, the control circuit for the rotating device is deactivated. The actuation of the special equipment via S5L and S5R is no longer possible. S20 – No function
S21 – Travel speed increase Press the touch: LED 1 in the touch illuminates, the automatic shifting from normal to increased travel speed is activated. During travel, the oil motors mounted to the travel gears now change automatically from normal speed to increased speed each time the terrain conditions allow it, and inversely, they return to normal travel speed when ground conditions become difficult. Press the touch again: LED 1 in the touch goes out, the automatic shifting between normal and increased travel speed is deactivated. The travel motors remain permanently in the normal travel speed position. S22 – Auxiliary floodlights (optional equipment) Press the touch: LED in the touch illuminates, the auxiliary floodlights are turned on. Press the touch again: LED in the touch goes out, the auxiliary floodlights are switched off. S36 – No function
S41 – Rotating beacon (optional equipment) Press the touch: LED in the touch illuminates, the rotating beacon is turned on. Press the touch again: LED in the touch goes out, the rotating beacon is switched off.
copyright by
3 - 10
MJFCIFSS
ER 954 C - High-Rise / 11211691
