Control and operation
Operating manual
Operating and control elements
S10 – Working floodlights Press the touch. Each touch actuation will successively: turn on the uppercarriage floodlights (LED 1 illuminates), turn on the attachment floodlights (LED 2 illuminates) switch off the uppercarriage floodlights (LED 1 go out), turn on both the uppercarriage and the attachment floodlights (LEDs 1 and 2 illuminate), switch off both the floodlights on the uppercarriage and the floodlights on attachment (LEDs 1 and 2 in the touch go out). S11 – Windshield washer Press the touch and keep it depressed: washer fluid is sprayed onto the windshield, the windshield wiper runs continuously. Release the touch: the washer fluid spraying is stopped, the windshield wiper will stop after approx 3 seconds. Windscreen washing fluid container
Fig. 3-6
Windscreen washing fluid container
The container for the windscreen washing fluid is located at the rear of the cab. Once the cover (see arrow) has been opened, the container can be refilled with ordinary windscreen washing fluid. For the machines equipped with a cab elevation, fill the container with precaution. Risk of tumble. Respect the local rules and safety instructions for the works in altitude. Volume: see lubricant chart
copyright by
3-8
MJFCIFSS
ER 954 C - High-Rise / 11211691
