5 Maintenance 5.1 Access doors for maintenance 5.1.1
Overview of access doors
Fig. 5-1
Access doors at the machine
10
Motor hood
120
Left doors
11
Motor hood
140
Right door
60 80
Motor hood Right hood
220 220
Front left hood Front left side door
Access door
Locking mechanism
Access to:
10 or 60
Motor hood
Gas pressure spring, with mechanical holding device
– Electric motor
11
Radiator hood
Gas pressure spring
– Radiator
80
Right hood
Gas pressure spring and screwed part
– Control oil unit – Hydraulic pump
120
Left side doors
Mechanical holding device
– Switch cabinet
140
Right side door
Mechanical holding device
– Control oil unit – Hydraulic pump
220
Front left hood
Gas pressure spring
– Heating box
Tab. 5-1
Access doors
