Control and operation
Operating manual
Installing and removing the serial counterweight
Installation of the counterweight Attach the lifting apparatus to the suspension points of the counterweight as described above. Check the correct position of the centering pins in the bores of the uppercarriage, lift the counterweight and set it down onto the supporting girders so that the centering pins 2 insert in the corresponding bores of the counterweight. Danger! Never stand below the counterweight while it is hanged up on the lifting crane. Engage the mounting bolts 3 with washers 4 and tighten. For tightening torque, see the heading "Mounting bolts of the counterweight" in the chapter maintenance of this manual. Caution! It is forbidden to operate the machine if all the mounting bolts of the counterweight are not installed and correctly tightened. The steel construction structures may be seriously damaged Remove the lifting devices from the suspension points of the counterweight.
copyright by
3 - 134
MJFCIFSS
ER 954 C - High-Rise / 11211691
