Control and operation
Operating manual
Attaching and dismounting equipment parts
Detaching a work tool To move the equipment into position: Caution! Hydraulic lines are pressurized! Remove the pressure using the joystick before removing the hydraulic lines (switch off the engine, turn the ignition key into the contact position, operate the joystick). Disconnect hydraulic lines or electrical lines, if necessary (eg. when dismounting a grab). Extend the shovel tilting cylinder fully. To unlock the quick-change adapter:
Fig. 3-102 Unlocking the quick-change adapter Danger! Risk of injury. Once unlocked, there is no fixed connection between the adapter and the work tool. The work tool could work itself out independently. Ensure that the work equipment cannot be moved by others when this action is being carried out. Always keep the work tool as close to the ground as possible when unlocking to avoid creating conditions which may lead to danger. Approach the quick-change adapter from the side and unscrew the locking screw 2 using the crank 3 from the locking pin 1. Insert the crank 3 in the locking pin 1 and turn to the left (anti-clockwise), until both locking pins 1 are inserted as far at the stop. To put down the work tool:
Fig. 3-103 Putting down the work tool
copyright by
3 - 112
