Control and operation
Operating manual
Attaching and dismounting equipment parts
Attaching the work tool To move the equipment into position:
Fig. 3-99
Positioning the equipment
The equipment must be standing stable or lay loose on the ground. Move the stanchion and work tool into position. Insert the shovel tilting cylinder fully. To unlock the quick-change adapter: Danger! Risk of injury. Ensure that the work equipment cannot be moved by others when this action is being carried out. Approach the quick-change adapter from the side and unscrew the locking screw 2 using the crank 3 from the locking pin 1 (see Fig. 3-98). Insert the crank 3 in the locking pin 1 and turn to the left (anti-clockwise), until both locking pins 1 are inserted as far at the stop. Taking up the work tool:
Fig. 3-100 Taking up the work tool Move the quick-change adapter into a position that allows the work tool to be picked up using the take-up hook. Raise the work tool from the ground and extend the shovel tilting cylinder fully until the bearing panel for the work tool is laying on the quick-change adapter stop. The bore holes of the work tool and the locking pins of the quick-change adapter must form a row.
