Control and operation
Operating manual
Working with the machine
Note! The driver’s cab cannot be raised as long as the valve is in position 2.
Emergency lowering from outside: From the outside of the cab it is also possible to engage the emergency lowering procedure using a shutoff valve located on the rear of the cab lifting device.
Fig. 3-84
Shutoff valve on the rear of the cab lifting device
Danger! Danger of crushing. Ensure that nobody is standing in the vicinity of the lifting frame when lowering the cab from the outside in an emergency. Ensure that you do not place any part of the body in the area of the moving parts when lowering the cab in an emergency. Turn the shutoff valve into position 2. the driver’s cab lowers as long as the shutoff valve is maintained in position 2. Return the shutoff valve into position 1 immediately after an emergency lowering. Note! The driver’s cab cannot be raised as long as the valve is in position 2.
Repair and maintenance Danger! Repair and maintenance work on the cab, lifting frame or on the related hydraulics system should be carried out – as far as possible – with the cab lowered. For repair and maintenance work which can only be carried out when the cab is raised, the cab should be supported by equipment which is suitable for this purpose.
copyright by
3 - 90
MJFCIFSS
ER 954 C - High-Rise / 11211691
