Control and operation
Operating manual
Working with the machine
Fig. 3-65
Straight path of the machine
– Stay within the cable tension limits. – Stay within the recommended distance range for the cable drum.
Switch off the cable drum Press the 0 key. The cable drum is switched off.
Troubleshooting Description of the control lights Caution! There is a hazard of driving on the power cable with the machine tracks or to snatch it because of an excessive tension. The control lights are on the right control desk of the cab and on the outside control box of the cable drum. control lights H153
Symbol on the outside control box
Symbol in the cab
Designation
Action(s)
Error in the cable drum switch cabinet
Contact an authorized and qualified electrician or the LIEBHERR customer service department
Cable drum is stopped
See "Setting the cable drum into operation".
Cable drum is off Cable drum in manual mode
See "Normal use of the cable drum".
copyright by
3 - 68
MJFCIFSS
ER 954 C - High-Rise / 11211691
