Control and operation
Operating manual
Working with the machine
switch is forcefully brought into position '1'.. Function security An interruption of the supply line or other control lines will not deactivate the immobilizer or delete data (e.g. data codes).. All relevant data are stored in a non-volatile memory. Magnetic fields will not deactivate the immobilizer.
3.4 Working with the machine 3.4.1
The travel movements Straight travel
Fig. 3-58
Straight travel
1
Idler wheel
5 Left travel pedal
2
Sprocket wheel
6 Right travel pedal
Caution! When travelling the machine, the upper carriage must be rotated to the undercarriage in such a way that ,during forwards travel, the idler wheel 1 is in front and the sprocket wheel 2 is at the rear. Travelling forwards: Push the both travel pedals forwards (5a + 6a). Travelling backwards: Push the both travel pedals down (5b + 6b). Caution! Before you travel in reverse, make sure the area behind the machine is free of any obstacle and nobody is in your way.
copyright by
3 - 62
MJFCIFSS
ER 954 C - High-Rise / 11211691
