Control and operation
Operating manual
Access and equipment of the cab
Danger! Close to operating temperatures, the elements of the heater system and the hydraulic system can reach extremely high temperatures. Do not touch any parts containing fluids or oil. There is a risk of injury from burns. Check the heater fluid level only after the lid of the expansion vessel has cooled down so that it can safely be touched by hand. Turn the lid carefully to relieve the overpressure.
Prior to commissioning
Fig. 3-42
Expansion tank in heating box
1
Expansion tank
20
10
Heating box
S206 Button
Plug
Filling expansion tank 1 with corrosion inhibitor and antifreeze agent: Open the plug 20. Fill the expansion tank 1 with corrosion inhibitor and antifreeze agent: Close the plug 20. Filling heating system: Press and hold the button S206. The booster pump is working. The heating system is filled. When corrosion inhibitor or antifreeze agent flows to the centre piece of the undercarriage: Release the button S206.
copyright by
3 - 46
MJFCIFSS
ER 954 C - High-Rise / 11211691
