Control and operation
Operating manual
Operating and control elements
S357 – Touch / Lifting the attachment while the grapple is being closed With this function, the working attachment is lifted slightly while the grapple is being closed. This reduces the risk of damage to the surface on which the grapple is used. Example: Protection of loading areas, ship bottoms and similar surfaces. Note! This function is an auxiliary tool designed to assist the machine operator. Even if the function is activated, the surface can still be damaged due to lack of care. S362 – Push button / Washer for cab roof window The button turns on the electric cab roof window washer system. Washer fluid will be sprayed to the window and the cab roof window wiper will be actuated as long as the push button S362 is depressed. S422 - Radio muting
S503 – Touch / Release in operator's cab See the section "Safety access to electric machines for industrial applications with self-stabilising tower superstructure" in this chapter. A – Additionnal standstill heater The additionnal standstill heater is only working when the main switch ist switched off (S184). Its performance is 1,1 kW. Two modes of operation are possible: – MANU/OFF mode is used to switch on/off the additionnal standstill heater independdently of the programmation of the automatic mode – AUTO mode is used as an automatic mode of the heater, progammed on time and day slot. Only an authorized personn can change the programmation of the additionnel stanstill heater.
Specific controls for cab movements .. of a cab on a hoist frame with double parallelogram
Fig. 3-30
Controls for adjustment of a cab on double parallelogram
copyright by
3 - 34
MJFCIFSS
ER 954 C - High-Rise / 11211691
