Control and operation
Operating manual
Operating and control elements
Fig. 3-21
Menu "Info In/Outputs"- Current to the solenoid valve EV3
Press the Menu key again. The screens 5, 6, 7 and 8/... are successively displayed.
Fig. 3-22
Menu "Info In/outputs" Status of electrical inputs and outputs
The screens 5/... to 8/... provide an overview of the status of the different electrical inputs and outputs. A“
” means "Input not active".
A“
”means "Input active".
An “NC” beneath the terminal designation means that the corresponding input has been deactivated in the software. The duration indicated in the last line of the screen 4/7, under M4/Time corresponds to the pause time for the windshield wiper in intermittent mode.
