Safety instructions, Signs on the machine
Operating manual
Signs on the machine
Signs (except for North America)
North America signs Plate 90: Prohibition sign - no lifting point* This sign is situated beside a lifting point. It is forbidden to use this point for lifting the complete position of the plates 45 for lifting the complete excavator.
Plate 91: Counterweight removal * Indicates the minimum angle to be respected by the loading slings when the counterweight is lifting off the machine.
The rubber weatherstrip can be loosened and removed and the rear window pushed out by pulling the clip on the inside of the rear window. *
Signage relating to optional equipments Standard signs
America signs Plate 101: Crushing hazard Signals of the high crushing hazard in those zones.
Plate 103: Hazard of thrown out objects Signals the hazard of injuries by thrown out objects wenn the fan is activated. (On machines fitted out with reversible cooler fan).
