Control and operation
Operating manual
Transport
Component
Undercarriage central part 954C - HR
Total weight (kg)
Length (mm)
Width (mm)
Height (mm)
15 000
4 150
4 600
3 700
Do not use the lashing points to lift the undercarriage. Use only appropriate lifting equipment to lift the undercarriage.
Tab. 3-4
Side frames 954C - HR
14 700
7 550
1 150
1 400
Uppercarriage
See next chapter.
Cab elevation 2 stages 944C - HR
2 108
3 853
-
2 384
Industrial boom 9,5 m
5 900
9 800
1 100
1 400
Industrial boom 11,5 m
8 750
11 900
1 200
1 600
Industrial boom 12,5 m
9 250
12 900
1 200
1 600
Industrial stick 8,8 m
2 987
8 800
975
1 047
Industrial stick 11,5 m
4 000
9 300
1 200
1 100
Industrial stick 12,5 m
4 400
10 300
1 200
1 100
Technical data of the main components of the machine
copyright by
3 - 154
MJFCIFSS
ER 954 C - High-Rise / 11211691
