Control and operation
Operating manual
Installation and removal of the counterweight
4
Counterweight
7
Mounting bolt
5
Additional counterweight
8
Mounting bolt
Fix the lifting slings on the eye bolts 6 fitted on the additional counterweight 5. Loose the mounting bolt 7 of the counterweight 4. Remove the counterweight 4 with the additional counterweight 5. Loose the mounting bolt 8 of the additional counterweight 5. Screw appropriate eye bolts on the counterweight 4. Fix the lifting slings on them. Move the counterweight 4.
3.9.4
Installation of a multi-parts counterweight
3
Counterweight shell
8
Mounting bolt
4 5
Counterweight Additional counterweight
9 14
Lifting plate Uppercarriage
6 7
Eye bolt Mounting bolt
15
Mounting bolt
Check the tightening torque of the mounting bolts 15 of the counterweight shell 3 on the uppercarriage 14 (M36 - 10.9; tightening torque 3300 N.m / 2430 ft.lbs).
CASE A: Fix the lifting plate 9 on the counterweight 4. Fix the lifting slings on them. respecting the recommendations. If your machine is fitted with an additional counterweight 5: 4 on the additional counterweight 5. 8 (M36 - 10.9; tightening torque 3300 N.m / 2430 ft.lbs). Let the lifting slings on the lifting plate 9.
CASE B without additional counterweight: Fix the lifting plate 9 on the counterweight 4. Fix the lifting slings on them. respecting the recommendations.
