Page 226

Control and operation

Operating manual

Installation and removal of attachment parts

Overview

Fig. 3-127 LIKUFIX 1

Protective cover on quick-change adapter

4

LIKUFIX hydraulic coupling on work tool

2

Protective covering on work tool

5

Alternative hydraulic coupling on work tool

3

LIKUFIX hydraulic coupling on quick-change adapter

Attaching and dismounting work tools

Fig. 3-128 Connecting LIKUFIX Please also note: Before attaching, remove the protective coverings on the quick-change adapter 1 and the work tool 2. Always keep hydraulic couplings 3 and 4 clean. Perform a visual check for cleanliness before attaching. If necessary, clean all coupling parts and the sealing surfaces with a clean, oil-soaked cloth.

copyright by

3 - 136

MJFCIFSS

ER 954 C - High-Rise / 11211691
