Control and operation
Operating manual
Installation and removal of attachment parts
Operating elements
Fig. 3-119 Operating elements for the hydraulic quick-change adapter
Switch S19 Use switch S19 to activate the auxiliary hydraulic device for the grab torsional mechanism and quick-change adapter. Press switch. Auxiliary device is activated. LED in switch illuminates. Press switch again Auxiliary device is deactivated. LED in the switch goes out. Key switch S47: Pressing the button activates the quick-change locking pins.
Pushbuttons L and R Pushbutton L = extend locking pin (lock) Pushbutton R = retract locking pin (unlock) The pushbuttons are located on the left and/or right joystick (depending on the
Fig. 3-120 Pushbutton on the joystick E
Operation with left joystick (standard)
F
Operation with left and right joystick (optional extras)
copyright by
3 - 130
MJFCIFSS
ER 954 C - High-Rise / 11211691
