Control and operation
Operating manual
Recovering, towing the machine
Machine towing procedure Drain the equipment. Make sure that the machine will not roll away by itself when the brakes are released. If necessary, put stop blocks in front of or behind the track. Open cover over travel motors and store carefully.
Fig. 3-108 Tap on travel motors (open position) Move tap on both travel motors to horizontal position. Pressure connections are connected to each motor.
1
Lever
2
Hand pump
Insert the lever in the hand pump. Operate hand pump to reach 30 bar. The travel brakes are released. Danger! Falling work equipment! Death, injury from crushing. When the work equipment is raised: Do not actuate joysticks.
copyright by
3 - 118
MJFCIFSS
ER 954 C - High-Rise / 11211691
