Control and operation
Operating manual
Working with the machine
Adjustment of the cab position The adjustment of the cab elevation is possible when the machine is ready to operate, with the safety lever pushed down and the engine running. Caution! Only adjust the cab when the machine is not travelling. height adjustment. The movements of the cab elevation with double parallelogram are controlled via the joystick U45 on the right side control desk. The joystick U45 is operative only as long as the touch S370 on the left control console is kept depressed. Movements of the cab side element I Press the touch S370 and at the same time tilt the joystick U45 to the right (n). the cab side element I raises, as long as the joystick is actuated. Press the touch S370 and at the same time tilt the joystick U45 to the left (m). the cab side element I is lowered, as long as the joystick is actuated.
Movements of the uppercarriage side element II Press the touch S370 and at the same time tilt the joystick U45 backwards (p). the uppercarriage side element II raises, as long as the joystick is actuated. Press the touch S370 and at the same time tilt the joystick S45 forewards (o). the uppercarriage side element II is lowered, as long as the joystick is actuated.
Safety cut off of cab lowering movements The cab lowering movements are automatically stopped when the cab arrives as low as about 2 meters above ground level. This safety cut off function prevents collision of the cab or cab support with the undercarriage. Unlatching the safety cut off I To let the cab down below the level where safety cut off occurs, the safety function must be unlatched while pressing the touch S477.
copyright by
3 - 108
MJFCIFSS
ER 954 C - High-Rise / 11211691
