Control and operation
Operating manual
Working with the machine
The emergency shutoff valve in the cab is on the floor below the right control panel.
Fig. 3-97
Emergency shutoff valve from the operator’s seat
Danger! Crushing hazard when lowering the hydraulic cab! Injuries, death. Make sure that nobody is in the dangerous area. Set the emergency shutoff valve in position 2. The cab lowers. When the cab is fully lowered: Set the emergency shutoff valve back in position 1. The cab can be lifted.
Emergency lowering from the uppercarriage The emergency shutoff valve on the uppercarriage is at the rear of the cab hydraulic lifting system.
Fig. 3-98
Emergency shutoff valve on the uppercarriage
