Control and operation
Operating manual
Working with the machine
Fig. 3-93
Commutation of proportional control for an additional attachment
The additional attachment can be operated alternatively with the right mini joystick or with the left pedals. The commutation of control can be activated with the touch on the right control desk. Press the touch. LED in the touch illuminates. The additional attachment is proportionally operated with the right mini joystick. Press the touch. LED in the touch goes out. The additional attachment is proportionally operated with the left pedals.
3.4.15
Cut-off of attachment movements (option) The movement cut-off restricts the movements of the boom cylinder or the stick cylinder. It enables: orking height, working depth, maximal reach, minimal reach). Danger! The movement cut-off is not a safety device! It is only an assistance to the driver during an attachment movement near a prohibited zone!
Caution! Danger of rocking motion of the machine and oscillations of the working tool! Avoid fast attachment movements close to a cut-off point. Note! The movement is only cut off to enter into the prohibited zone. The movement to leave it remains possible.
Adjustment of the movement cut-off point At the time of the cut-off, the attachment can enter into the prohibited zone in case of oscillations of the working tool, variations of its dimensions (open/close position) or attachment inertia. Danger! The machine driver is responsible for the adjustments precision! You must keep a safety margin of at least 1.5 m from the prohibited zone. As soon as the proximity switch detects the reflector, the movement is cut off. The proximity switch or the reflector position is adjustable depending on the configurations.
copyright by
3 - 98
MJFCIFSS
ER 954 C - High-Rise / 11211691
