Control and operation
Operating manual
Working with the machine
3.4.14
Commutation of control for an additional attachment (option) Danger! Risk of accident due to an unintentional movement by an uninformed machine operator! When the commutation of the control is turned on, the correspondence between the controls and the working movements is changed. When the key is removed from the switch or when the touch is gone out, the machine can be operated only with the usual control system, installed at machine delivery. It is the responsibility of the owner of the machine to grant an operator authorization to operate the machine with the activated special control system. Caution! Check out the functions of the additional controls when starting the machine, especially when a commutation of control is activated.
Standard control
Fig. 3-91
Commutation of standard control for an additional attachment
The additional attachment can be operated alternatively with the left double pedal or with the right joystick. The commutation of control can be activated with the key switch S114 on the rear right control desk. Turn the key switch S114 to select the joystick position. The additional attachment is now operated with the right joystick (movements to e and f). The bucket tilt function is now operated with the left double pedal (m-k). The key is locked in the switch S114. Turn the key switch S114 to select the foot pedal position. The additional attachment is now operated with the left double pedal again. The key can be removed from the switch S114.
copyright by
3 - 96
