Control and operation
Operating manual
Working with the machine
Fig. 3-83
Positioning swing brake pedal
Note! Increased wear. Do not use the positioning swing brake purely as a service brake, but only as a stop and parking brake. Using this brake to stop the uppercarriage running at the full swing RPM is not permissible since this would result in a quick abrasion of the brake discs. In any case, first use the hydraulic braking to greatly reduce the speed of the uppercarriage Depress the pedal 10 when the uppercarriage is near standstill The uppercarriage can be stopped precisely and progressively in the desired position.
3.4.8
Working position Work on a level, flat and firm ground. If necessary arrange the working place and free it of obstacles. As a general rule, work with the attachment over the idler wheels.
Fig. 3-84
Working position of the machine
copyright by
3 - 88
MJFCIFSS
ER 954 C - High-Rise / 11211691
