Control and operation
Operating manual
Working with the machine
Fig. 3-80 11 12
Switch on external control unit
Automatic mode Manual operation
31 32
Unwind cable Wind cable
Move safety lever up. Switch off electric motor of machine. Remove the ignition key. Go to the external control unit. If necessary, walk around the machine to avoid climbing over power cable. Activate automatic mode: turn key of switch 1 to 12. Manual operation of motor cable drum with controls is activated. Key in switch 1 is locked.
Suppression of tensile cable interference Notice! Loosening of windings on motor cable drum with controls! Damage. Do not let the cable sink to the ground. Ensure that no one is in the work area of the machine, of the motor cable drum with controls or of the power cable. Select movement of motor cable drum with controls with switch 3: 3 to 31. 3 to 32. Observe illuminated indicator light. Once indicator light goes out: stop movement.
Reactivating automatic mode Caution! Unexpected movement of motor cable drum with controls! Crushing, injuries. Maintain safety distance to motor cable drum with controls. Turn key of switch 1 to 11.
copyright by
3 - 84
