Control and operation
Operating manual
Working with the machine
In automatic mode 11: machine movements. In manual operation 12: 1 is locked.
Using the motor cable drum with controls Start the motor cable drum with controls Ensure that the following conditions are fulfilled: Automatic mode is activated: key of switch 1 of external control unit is turned to 11. Off switch 4 of external control unit is unlocked. No one is in the work area of the machine, of the motor cable drum with controls or of the power cable. Energise the machine circuit. Start electric motor. The control of the motor cable drum with controls is on the right console of the operator's cab. Press button 0. Control of motor cable drum with controls is installed. Press I button. Motor cable drum with controls is switched on.
Using machine equipped with motor cable drum with controls Danger! Danger of crushing or tearing off the power cable! Damage, injuries, danger to life. Observe specific driving regulations. Observe indicator lights.
Fig. 3-79
Working area of the machine
1
Working area 2
2
External supply station
3
Working area 1
Observe the following regulations:
