Control and operation
Operating manual
Working with the machine
Danger! Wrench of the power cable! Damage. Do not keep on travelling in initial direction when travelling out of the critical area. Travel out of the critical area within the 3 minutes.
In manual mode 12: Note This mode is used for maintenance tasks.
3 is locked on manual mode 15. er cable is controlled manually. To control the independent motor cable drum manually: turn the manual mode key 2 to the right or to the left. cabinet of the motor cable drum turns on. ll or almost empty: a buzzer starts to sound and the warning light reel almost empty / full 9 turns on. y: the machine is automatically switched off. Note Remove the key in the switch 3 out of the switch when the machine is not in use.
3.4.4
Lateral motor cable drum with controls (option) The lateral motor cable drum with controls is mounted on the left side of the undercarriage of the machine. Follow the instructions in the operator's manual of the motor cable drum with controls. Danger! Energised power cable, drum and control cabinet! Electric shock, danger to life. Do not touch components when energised. Lock the main circuit breaker of the supply station before carrying out any maintenance work.
Description of the motor cable drum with controls Description of the controls The controls of the motor cable drum with controls are installed in the following locations:
copyright by
3 - 80
MJFCIFSS
ER 954 C - High-Rise / 11211691
