Control and operation
Operating manual
Working with the machine
3.4 Working with the machine 3.4.1
The travel movements Straight travel
Fig. 3-63 1 2
Straight travel
Idler wheel Sprocket wheel
5a / 5b Pedal for travel left 6a / 6b Pedal for travel right
As a basic rule, when travelling, the upper carriage must be rotated to the under carriage in such a way that when travelling forwards, the idler wheel 1 is in front and the sprocket wheel 2 is at the rear. Danger If the uppercarriage us turned by 180°, note that all travelling directions (right and left, forward and backward) are reversed when you push the pedals! Travel forwards: Push both pedals forward at the same time (5a and 6a). Travel backwards: Caution! Before travelling in reverse, ensure that the area behind you is clear and nobody is in your way. Push both pedals down at the same time (5b and 6b).
copyright by
3 - 68
MJFCIFSS
ER 954 C - High-Rise / 11211691
