Control and operation
Operating manual
Setting the machine into operation
Check the controls function Move the safety lever to the down position. Check the controls function: carefully operate the joysticks and pedals. Check the slewing gear brake is functioning correctly.
Preheating of the hydraulic system If the hydraulic oil temperature is below 8 °C: current warm up phase is displayed. As soon the hydraulic oil temperature rises above 8 °C, the full power of the machine is available. Note The warm up phase for the hydraulic circuit can be activated and deactivated at the display.
Starting procedure failure If the motor does not start: Wait for at least 10 minute before the next attempt to start the motor. If the motor is cold: try maximun 3 starts. If the motor is warm: try maximun 2 starts. If there are two unsuccessful attempts to start the motor, establish the cause of the fault and eliminate it.
3.3.4
Shutting down the machine
2 buttons
Fig. 3-59
Buttons in right armrest
copyright by
3 - 62
MJFCIFSS
ER 954 C - High-Rise / 11211691
