Control and operation
Operating manual
Setting the machine into operation
Switching on control system Press the button S183. The indicator light in the button S183 lights. The keyboard and the monitoring display complete a self-test. Check all indicators and instruments for proper functioning. All indicator lights must be briefly on, except the LED of the switch S22. The LIEBHERR logo is displayed. After the self-test is completed, the next service task deadline is displayed for 10 seconds. Check the next service task deadline. See chapter 3 "Main screen". Note! If no self-test of the keyboard and the monitoring display is performed: Check that the immobiliser has been deactivated. See chapter 3 "Immobiliser (option)".
Emergency operation (option)
Fig. 3-56
Battery main switch S9
Set the battery main switch S9 (on the heating box behind the operator's cab) to position 1.
Collector overheating surveillance (option)
Fig. 3-57
Collector overheating surveillance
copyright by
3 - 60
MJFCIFSS
ER 954 C - High-Rise / 11211691
