Control and operation
Operating manual
Access and equipment of the cab
a the windscreen is closed. b the windscreen is fully opened (locked in place on the roof of the cab) Caution! It is not allowed to work with the machine when the windscreen is in an intermediate position! To change the position of the windscreen Pull the lever 1 in and down to unlock the windscreen. Move the windscreen using the handle 2, secure it in one of the two positions a or b and relock using the lever 1.
3.2.6
Sunshade
Fig. 3-38
Sunshades at windscreen and at cab roof
The cab is provided with two sunshades, located at the windscreen and at the cab roof window. Manoeuvring the sunshade at the windscreen Using the strengthening tongue 1, pull the sunshade down to the desired position. Press the red button 2, the sunshade will roll itself up. Manoeuvring the sunshade at the cab roof Pull out the sunshade and secure it in the holders designed for the purpose. To retract the sunshade, take it out of the holders and let it roll up slowly.
copyright by
3 - 44
MJFCIFSS
ER 954 C - High-Rise / 11211691
