Control and operation
Operating manual
Access and equipment of the cab
Getting in the cab Caution! Entering or leaving the cab incorrectly could lead to injury. Ensure that the safety lever is always in its highest position when entering or leaving the cab. Do not hold onto the controls to steady yourself.
Fig. 3-32 1
Door - exterior
Door handle
2
Latch
11 Door lock
Press the door lock 11 on the door handle 1 and open the door. If the door is to remain open during operations, swing the door back 180° and secure in the latch 2. Climb in with your face to If necessary adjust the seat horizontally vis-à-vis the joystick consoles and also vis-à-vis the feet plate with the control pedals.
Getting out the cab
Fig. 3-33 3
Door - interior
Door handle on door lock
4
Lever for the latch
copyright by
3 - 38
MJFCIFSS
ER 954 C - High-Rise / 11211691
