Control and operation
Operating manual
Operating and control elements
This push button is mounted serially.
The pause time of the intermittent mode of the cab roof window wiper can be adjusted by turning this button. (The window wiper is switched on and off using the touch S218).
If the touch S98 is actuated, the pressure protection value for lowering the attachment (circuit for retraction of the boom cylinders) is reduced, so to limit the possible downward thrust exerted by the working attachment onto the materials to be dug out. This safety device must be turned on, as an example, when unloading a boat or a barge, so to avoid damage to its bottom.
Thanks to this switch, the operator can control the movement of the additional user of an add on kit AHS either using the double pedal destined for this purpose (key switch in position "pedal")., or via the right joystick (key switch in position "joystick"). See also "Commutation of the control for the user of add on kit AHS" in this chapter.
On machines fitted with the special equipment "cooler fan reversible", the direction of revolution of the cooler fan can be inverted while actuating the push button S160. In some particular working conditions, this inversion of the direction of the fan rotation allows an easy cleaning of the radiator core and of suction area of the fan. See also the section "Reversible cooler fan (Optional equipment)" in the chapter "maintenance".
Option on the High-Rise or High-Pedestral machines. See "Access to the cab". n when operating a super long working attachment When using a long reach attachment (super long working attachment with a smaller digging tool), this device allows to limit the working pumps oil flows to a value admissible for all the hydraulic cylinders of the working attachment. Turn the key switch S168 to the right, in po movements of the working attachment. draulically adjustable cab See the section "Hydraulically adjustable cab (option)" in this chapter.
copyright by
3 - 34
MJFCIFSS
ER 954 C - High-Rise / 11211691
