Control and operation
Operating manual
Operating and control elements
When a service connector is pluged in: The submenu list S-Exxx lists all the operating faults, just like the submenu list Exxx, but this time only faults appeared in service mode, i. e. when a service connector was connected. The sub-menu allows to separate the faults occuring during maintenance works,in particular during the troubleshootings. For each error, an overview is shown and can be paged in just like for the "list Exxx" selection. When exiting the service mode, the memory "list S-Exxx" is reset, the service mode operating faults are not stored.
Menu "set clock" - Time setting Via this menu the clock displayed in the upper right corner of the main screen can be set.
Fig. 3-27
Setting of the clock
After function start, the presently set time will appear in the lower section of the screen with the digit completely right inversely displayed (unity digit of the minutes). Press the UP or DOWN key to adjust the selected digit. Press the MENU key: the immediately more left digit is now inversely displayed. Repeat the procedure until all the digits have been set. Press the Enter key:
Fig. 3-28
Confirmation of the storage of the new time
The confirmation message ear momentarily on the screen and the new time is stored. The menu "set clock" is closed and the main menu is displayed on the screen.
copyright by
3 - 30
MJFCIFSS
ER 954 C - High-Rise / 11211691
