Control and operation
Operating manual
Operating and control elements
There are 3 possible choices in this menu: list Exxx, all the operating faults detected by the switches and sensors monitoring the machine parameters are listed. list E-elec, all the electrical system errors (cable errors, sensor errors, ...) detected during the operation of the machine are listed. list S-Exxx, all the operating faults are listed, just as with the selection list Exxx, but this time only faults which appeared when the service connector was connected . To select the desired error type: Press the Down or Up arrow key: the previous, respec. the next error typ is preselected Press the Menu key. The sub-menu on a black background will be displayed. If more than 6 error codes are listed, use the arrow keys Down or Up to scroll in the list. "list Exxx": Operating faults
Fig. 3-24
List of the operating faults (fig. left) and occurrences of a fault (fig. right)
Select list Exxx. Press the Menu button: the first page of the sub-menu appears. All the operating faults are listed with their error code and number of occurences. Select the desired error code using the Down or Up arrow key. Press the Menu key again: the second page of the sub-menu appears. A screen appears with the operating hours and the duration for the ten first and the ten last occurrences of the selected error. Press the Back key: the first page of the sub-menu appears. Press the Back key again, to select another error type, or press the Down or Up arrow key, to preselect another error code. The asterisk "*" shows that the error was also indicated by the buzzer and then acknowledged using the Back key. .
copyright by
3 - 28
