Control and operation
Operating manual
Operating and control elements
re-Versions for, respectively, the monitoring display, the control unit and the pump regulator BST. The areas provided on the second line are neither employed nor active on electric powered machines.
actually), actually), actually), Press the Menu key again. The screen 1/... is displayed. To exit the menu: Press the Back key. The sub-menu will be aborted.
Menu "Info In/Outputs"- Status of hydraulic pumps and of electrical inputs and outputs The screens 1 to 3 provide information on the regulation parameters for the hydraulic pumps.
Fig. 3-19
Menu "Info In/Outputs" Active flow and pressure limitations
The screen 1/... displays: active flow limitation option and which percentage of the maximum flow is set (solenoid valves EV1 and EV2). essure limitation for the hydraulic system and which percentage of the maximum pressure is set (solenoid valve EV6). regulation solenoid valves.. On the left picture, an external limitation (Hardware input I1, option 2) is activated. The currents supplying the flow limitation solenoid valves EV1 and EV2 limit these flows to 55% of their maximal values. The current supplying the pressure limitation solenoid valve EV6 limits the pressure to 80% of its maximal value.
copyright by
3 - 24
MJFCIFSS
ER 954 C - High-Rise / 11211691
