Control and operation
Operating manual
Operating and control elements
Note A light sensor built in to the top left of the monitoring screen adapts the illumination on the main screen to the brightness of the environment. The adaptation takes place from the saved brightness value. Illumination will be automatically reduced in conditions of low environmental brightness and inversely. To change the brightness and the contrast setting to the initial setting: Turn off the ignition. Press and hold the Up and Down keys simultaneously. Turn on the ignition again. After completion of the automatic display check release the both keys.: the settings for the brightness and for the contrast of the LCD screen retrieve their initial values set at machine delivery.
3.1.5
Main screen The main screen appears when the machine has been switched on and remains on display until the screen is changed over to the menu selection screen using the Menu key.
Fig. 3-9
Main screen - Division into four fields
EC
Error codes of electrical SY errors
Symbols of operating faults, clock
INF
Information symbols
Display of hour meters, flow limitations, ...
TI
Constitution of the main screen SY field The upper field of the screen shows the warning symbols for the actual operating faults and also the clock. Should more than two symbols be shown, so the clock is not displayed any more and up to four symbols can be shown at the same time in the field SY. If more than 4 symbols must be shown, then every 10 seconds, the symbols move to the left by one symbol.
copyright by
3 - 14
MJFCIFSS
ER 954 C - High-Rise / 11211691
