4 - ASSEMBLY
34. Pass the hydraulic hose (28) under the cab from the front right-hand side. Move the hose (28) through the right-hand side of the engine compartment to the blade control valve (2). NOTE: this operation requires two people.
LEIL16GRD0039AB
22
LEIL16GRD0040AB
23
LEIL16GRD0041AB
24
35. Connect the hose (28) to the fitting (5) installed on the blade control valve (2), as shown in figure 23.
36. Connect the loose end of the hose (28) to the fitting (20) installed on the socket tee (22) of the port “B” on the lower control valve.
21 EN
