4 - ASSEMBLY
25. Install the fitting (21) on the port “A” of the lower control valve. 26. Install the socket tee (22) on the fitting (21) on the lower control valve. 27. Install the two fittings (20) on the socket tee (22) on the lower control valve. 28. Connect the loose end of the hose (32) to the lower fitting (20) installed on the socket tee (22) (lower control valve), as shown in figure 19. 29. Install the socket tee (22) on the fitting of the port “A” on the upper control valve. 30. Install the fitting (20) on the socket tee (22) on the upper control valve. 31. Install the socket 90° elbow (25) on the fitting (20) installed on the socket tee (22) (upper control valve), as shown in figure 19.
LEIL16GRD0036BB
19
LEIL16GRD0037AB
20
LEIL16GRD0038AB
21
32. Disconnect the hose (AF) from the port “B” of the lower control valve on the front of the cab.
33. Install the socket tee (22) on the fitting of the port “B” of the lower control valve on the front of the cab. Install the fitting (20) on the socket tee (22), as shown in figure 21
20 EN
