4 - ASSEMBLY
21. Pass the hydraulic hose (32) under the cab from the front right-hand side. Move the hose (32) through the right-hand side of the engine compartment to the blade control valve (2). NOTE: this operation requires two people.
LEIL16GRD0033AB
16
LEIL16GRD0034AB
17
LEIL16GRD0035AB
18
22. Connect the hose (32) to the fitting (5) installed on the blade control valve (2), as shown in figure 17.
23. Disconnect the hoses (AA), (AB) and (AG) from the upper control valve on the front of the cab. 24. Disconnect the hoses (AC), (AD) and (AE) from the lower control valve on the front of the cab. Remove the fitting (Z) from the port “A” of the lower control valve. NOTE: the removal of the hoses (AA), (AB), (AC), (AD), (AE) and (AG) is necessary in order to gain access to install and tighten the hydraulic hoses and fittings to be installed.
