4 - ASSEMBLY
NOTICE: the weight of the blade control valve (2) and bracket (1) assembly is approximately 13 kg (28.7 lb). Have another person help you to lift and install the assembly on the machine. 4.
WARNING Heavy object! The following instruction requires two people. Failure to comply could result in death or serious injury. W1270A
Install the blade control valve (2) and bracket (1) assembly on the hydraulic tank, on the rear of the machine. Use the four washers (7), the four lock washers (8) and the screws (9) to fix the blade control valve (2) and bracket (1) assembly on the hydraulic tank. LEIL16GRD0020AB
3
Hydraulic components installation NOTE: the installation of the moldboard control hydraulic hoses requires two people to pass the hydraulic hoses through the engine compartment, and, when necessary, under the cab to route the hydraulic hoses to the front control valves. The hydraulic hoses (11), (17), (28), (29), (30), (31), (32) and (33) are routed on the right-hand side of the engine compartment. The hydraulic hose (10) is routed on the left-hand side of the engine compartment. NOTE: when disconnecting the hydraulic lines, keep the hydraulic hoses and fittings plugged until final connection to prevent contamination into the hydraulic system. 5. Connect the hydraulic hose (11) to the front fitting (3) (port “T”) installed on the blade control valve (2).
LEIL16GRD0021AB
4
LEIL16GRD0022AB
5
6. Locate the hose (X) on the right-hand side of the machine. Disconnect the hose (X) from the T-fitting (already present) installed on the hydraulic tank.
